Introduction
The lollipop depositing production line adopts advanced automation technology, realizing fully automated production from raw material processing to finished product packaging, thus improving production efficiency; through advanced control systems, it can achieve precise control of production parameters such as temperature, humidity, and speed, ensuring the stability and consistency of lollipop quality; the production line can flexibly meet various flavor, shape, and packaging requirements, catering to diverse market demands. Whether it's traditional fruit flavors or innovative cream-filled ones, production can be easily achieved on the production line.
Paramater
Model | GD150B-S | GD300B-S | GD450B-S | GD600B-S | GD1200B-S |
Capacity | 150kg/h | 300kg/h | 450kg/h | 600kg/h | 1200kg/h |
Lollipop weight | As per the lollipop shape and size | ||||
Depositing speed | 25-35n/min | 30-60n/min | |||
Steam requirement | 250kg/h,0.5-0.8MPa | 300kg/h, 0.5-0.8MPa |
400kg/h, 0.5-0.8MPa |
500kg/h,0.5-0.8MPa | 1200kg/h,0.5-0.8MPa |
Compressed air requirement |
0.2m3/min, 0.4-0.6MPa |
0.2m3/min, 0.4-0.6MPa |
0.2m3/min, 0.4-0.6MPa |
0.3m3/min, 0.4-0.6MPa |
0.6m3/min, 0.4-0.6MPa |
Working condition | Temperature 20°C-25°C; Humidity45-55% | ||||
Electric power needed | 18kW/380V | 27kW/380V | 34kW/380V | 38kW/380V | 56kw/380V |
Total length | 17m | 19m | 19m | 22m | 40m |
Weight of machine | 4000kg | 5000kg | 6000kg | 7000kg | 12000kg |
Important reminder
1 The technical parameters are for reference only.
2 The product quotation is for reference only, It is based on the actual purchased model and configuration.
3 For more information, please call or consult customer service.
Q1. What is the production capacity of the lollipop pouring line?
The production capacity depends on the specifications and configuration of the line, usually customizable to produce from thousands to tens of thousands of lollipops per hour.
Q2. Does the line support customization of lollipop shapes and flavors?
Yes, lollipop pouring lines typically support customization of shapes, flavors, and colors to meet different customer demands.
Q3. How do you clean and maintain the lollipop pouring line equipment?
Cleaning and maintenance usually follow the equipment's operation manual, including regular cleaning, lubrication, and inspection of parts for wear and tear.
Q4. What energy sources and auxiliary equipment does the line require to operate?
The line typically requires electricity as the primary energy source, possibly supplemented by compressed air and equipped with conveyors, packaging machines, and other auxiliary equipment.
Q5. Does the lollipop pouring line have automated production capabilities?
Yes, most lollipop pouring lines utilize advanced automation technology, enabling fully automated production from raw material processing to finished product packaging.
